| Selection Guide |
Model
Data Sheet |
Cell Size Ref |
Catalog No. |
Nominal Voltage (V) |
Nominal Capacity (Ah) |
Nominal Discharge Current (mA) |
Temperature range (°C) |
Maximum Dimensions |
| |
|
|
|
|
|
|
Diameter |
Height |
| |
|
|
|
|
|
|
(mm) |
(in) |
(mm) |
(in) |
| TLL-5902 |
1/2 AA |
15-5902-yy530 |
3.6 |
1.10 |
1.0 |
-55° to +85° |
14.5 |
0.571 |
25.2 |
0.992 |
| TL-5955 |
2/3 AA |
15-5955-yy500 |
3.6 |
1.50 |
1.3 |
-55° to +85° |
14.5 |
0.571 |
33.5 |
1.319 |
| TL-5903 |
AA |
15-5903-yy500 |
3.6 |
2.40 |
2.0 |
-55° to +85° |
14.5 |
0.571 |
50.5 |
1.998 |
| TL-5920 |
C |
15-5920-yy500 |
3.6 |
8.50 |
3.0 |
-55° to +85° |
26.2 |
1.031 |
50.0 |
1.970 |
| TL-5930 |
D |
15-5930-yy500 |
3.6 |
19.00 |
4.0 |
-55° to +85° |
32.9 |
1.295 |
61.5 |
2.421 |
| TL-5937 |
DD |
15-5937-yy500 |
3.6 |
35.00 |
10.0 |
-55° to +85° |
32.9 |
1.295 |
124.5 |
4.902 |
|
| |
| |
|
|
|
|
|
|
| Termination Suffix |
/S |
/T |
/P |
/TP |
/PT |
/PT2 |
| YY |
21 |
31 |
41 |
52 |
53 |
36 |
|
|
